SOMMER CABLE “Ultra High Definition”

The transmission of high definition signals at 4k or even 8k often presents a challenge in the cable connections of broadcast production devices such as cameras, monitors, or editing consoles and their connection and transmission technology. This is one reason why the consumer demand is increasing for solutions that meet the high demands.

TRANSIT MC3202 HD from SOMMER CABLE

With the TRANSIT MC 3202 HD, SOMMER CABLE presents a high-performance combination cable in the area of Ultra High Definition. There is a wide range of possible uses for the cable – regardless of whether for big events, in studio use, or a transmission truck.

"Ultra High Definition is making real progress new," emphasized Pascal Miguet, Product & Sales Manager at SOMMER CABLE.

He went on to say: "The cable can hold its own wherever things depend on a stable UHD signal transmission, while keeping things compact."

Overview of Facts and Functions:

The TRANSIT MC 3202 HD is a so-called "UHD-SDI hybrid cable" and supports the series of fiber optic combination cables already available. The cable includes three UHD Video (BNC), two digital Audio (XLR 3-pole) and one camera power supply (e.g. XLR 4-pole). Additional areas of application include studios and broadcast productions as well as outdoor events. The low emission levels make it equally suitable for long distance transmissions, which is especially good for event organizers.

Technical Data TRANSIT MC 3202:

- Properties: SDI/HD-SDI
- Properties: Analog
- Properties: 3G-SDI
- Properties: 6G-SDI
- Properties: Digital 75 Ω
- Properties: OFC oxygen free copper
- Setup: 3x1.2L/5.0+2x(2x0.14mm²)+2x0.75mm²
- Setup (audio): 2x(2x0.14mm²)
- Setup (video): 3x1.2L/5.0
- Setup (control): 2x0.75mm²
- Case material: PVC
- Wire insulation material (video): Foam / Skin-PE
- EAN: 4049371268905

Prolight + Sound 2017

Whoever would like to see the new product for themselves can find SOMMER CABLE as an exhibitor at this year’s Prolight + Sound in Halle 4, level 1 (Stand G20). Further information about the manufacturer as well as production methods can be found here.

You can get a precise overview of the hall map and the other exhibitors here.
